Additive Manufacturing–think economically!

Automation

A 6-axis industrial robot overcomes the usual limitations of component size and design complexity. In order to ensure reproducible dimensional accuracy and high surface quality and at the same time prevent a limitation of component complexity, subtractive processes (e.g. milling, drilling) are integrated into the manufacturing process by combining the additive structure and machining in one manufacturing system.

Based on this approach it is also possible to integrate inserts such as threaded or bearing bushes, injection moulded parts, electronic or ceramic inserts and to equip the component under construction with further functions. For this purpose, the eingine used for extrusion and machining operations is equipped with a standardised tool changing system, thus ensuring maximum automation and flexibility

Additive Manufacturing

Subtractive Manufacturing

Insert integration

Handling operations

Material diversity

Thermoplastic pelets can be used to reduce costs

Due to the underlying screw-based extrusion process, industry-standart granulates can be used. This makes it possible to fall back on teh wide range of thermoplastics without the need to produce a powder or a monofilament. The low costs are directly displayed in the low component costs.



Benefits Pellets:

  • High availability
  • Cheap
  • Godd eligibility from one central stock

    (allows scalling of product lines)

  • Special extruding technology allows low variation of extruding rate

Productivity

The high productivity of the process is based on the physical principal of shear heating within the screw extruder. Contrary to pure plasitfication over heat distribution a scalable and indipendent of the materials thermal conductivity delivery rate is possible to achive. The delivery rate can reach up to several kilogramms per hour.

Diameter: 16 mm

Temperature controle: 1 cooled zone, 3 heated zones

Max. temperature: 400 °C

Pellet size: > 8 mm rod pellets

Possible Materials:
Thermoplastics (filled and unfilled)

The central screw-based plasticizing unit is operated with conventional thermoplastic granulate. Compared to filament-based production technologies, this enables the processing of unfilled, but also highly filled plastic compounds with simultaneously high and scalable throughputs. In addition the possible high throughput results in a significant cost advantage for the processing of engineering thermoplastics, depending on the material, due to the low price of granulate (approx. 1 to 8 €/kg) compared to filament (approx. 20 to 500 €/kg).

As with all manufacturing processes, the production results depend on the process capability of the material used. This essentially concerns the aspects of dimensional accuracy (shrinkage gears) and mechanical properties (adhesion gears).

The SpaceA – Product family

Building Plattform Modul

  • Piece Carrier System
  • Conveyor Belt
  • Turn Table
  • Fixed Platform
  • More options on request
'
P

Manufacturing Modul

  • Screw Extruder
  • Milling Cutter
  • Gripper
  • Pellet Dryer
  • More options on request
(

SpaceA -1 2000-500 Hybrid2 / Werkstückträgerfördersystem

Robot Configuration 1: One Robote 2L: Two Robots IMM: Combined with Injection Moulding Machine

Handling Area [mm] 500 1000 1500 2000 More on request
Throughput [g/h] 500 1000 2000 4000 More on request
Extruder Configuration Single Hybrid     More on request
Number of Extruder 1 2 3 4 More on request
Interface

Piece Carrier System

Conveyer Belt Turn Table Fixed Plates More on request
